Lenovo ThinkSystem SR630 V2 1U Rack Server (7Z71TANU00)

Lenovo ThinkSystem SR630 V2 1U Rack Server (7Z71TANU00)

$4,950.00 SGD
$4,950.00 SGD
Sale Sold out
Shipping calculated at checkout.
View full details

Product Description

The Lenovo ThinkSystem SR630 V2 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

  • 16 GB powerful memory for any computational task
  • RAID provides data reliability, fault tolerance and improves overall performance
  • Gigabit Ethernet is very useful when a large number of file transfers are required such as when performing backups over the network
  • 1 x 1.10 kW power supply unit (PSU) for your system's power requirements
Network & Communication
Ethernet Technology Gigabit Ethernet
Warranty
Additional Warranty Information

3 Y P L, Onsite, 2Hr, 24x7
Chipset
Chipset Manufacturer Intel
Chipset Model C621A
Display & Graphics
Graphics Controller Model G200
Graphics Memory Capacity 16 MB
Controllers
RAID Levels 0, 1, 5, 10
Controller Type 12Gb/s SAS
RAID Supported Yes
Controller Model 5350-8i
Physical Characteristics
Weight (Approximate) 20.80 kg
Form Factor Rack
Rack Height 1U
Height 43.2 mm
Width 439.4 mm
Depth 772.2 mm
Interfaces/Ports
VGA Yes
Number of Network (RJ-45) Ports 4
Network (RJ-45) Yes
Remote Management No
Total Number of USB Ports 6
Number of USB 2.0 Ports 1
Number of VGA Ports 1
I/O Expansions
Riser Card 1 x ThinkSystem 1U PCIe Gen4 x16/x16 Riser 1
"Number of Internal 2.5"" Bays" 8
Number of Total Expansion Bays 8
Total Number of Expansion Slots 2
Hot Swappable Bays Yes
PCI Express x16 (Gen 3.x) Slots 2
Number of SFF Bays 8
PCI Express Details 1 x ThinkSystem 1U PCIe Gen4 x16/x16 Riser 1
Power Description
Input Voltage 230 V AC
120 V AC
Power Source Power Supply
Plug/Connector Type C13
Number of Power Supplies Supported 2
Number of Power Supplies Installed 1
Hot Swappable Power Supply Yes
Maximum Power Supply Wattage 1.10 kW
Processor
Cache 12 MB
Processor Speed 2.80 GHz
Processor Type Xeon Silver
Processor Model 4309Y
Processor Core Octa-core (8 Core)
Number of Processors Supported 2
Number of Processors Installed 1
Processor Generation 3rd Gen
General Information
Product Type Server
Manufacturer Part Number 7Z71TANU00
Manufacturer Website Address http://www.lenovo.com
Manufacturer Lenovo Group Limited
Product Model 7Z71TANU00
Product Name ThinkSystem SR630 V2 7Z71TANU00 Server
Product Line ThinkSystem
Product Series SR630 V2
Brand Name Lenovo
Memory
Error Checking ECC
Maximum Memory Supported 8 TB
Signal Processing Registered (Buffered)
Standard Memory 16 GB
Memory Technology TruDDR4
Number of Occupied Memory Slots 1
Intel Optane Memory Ready Yes
Memory Clock Speed 3.20 GHz
Total Number of Memory Slots 32
Miscellaneous
Package Contents
  • ThinkSystem SR630 V2 7Z71TANU00 Server
  • 1 x ThinkSystem Toolless Slide Rail Kit v2
  • C13 to C14 Jumper Cord
Security Features
  • Chassis Intrusion Switch
  • Power-on Password
  • Administrator's Password
  • Trusted Platform Module (TPM), supporting TPM 2.0
Environmentally Friendly Yes
Environmental Certification China Environmental Labeling Program (CELP)
GREENGUARD
Energy Star Yes
Energy Efficiency Certification China Energy Conservation Program (CECP)
Energy Efficiency Compliance Energy-related Products Directive Lot 9 (ErP Lot 9)
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Operating System
Operating System Supported Windows Server 2016
Ubuntu 22.04 LTS x64
Windows Server 2022
Red Hat Enterprise Linux 7.9
Red Hat Enterprise Linux 8.2
Red Hat Enterprise Linux 8.3
Red Hat Enterprise Linux 8.4
Red Hat Enterprise Linux 8.5
Red Hat Enterprise Linux 8.6
Red Hat Enterprise Linux 8.7
Red Hat Enterprise Linux 8.8
Red Hat Enterprise Linux 9.0
Red Hat Enterprise Linux 9.1
Red Hat Enterprise Linux 9.2
SUSE Linux Enterprise Server 12 SP5
SUSE Linux Enterprise Server 15 SP2
SUSE Linux Enterprise Server 15 SP3
SUSE Linux Enterprise Server 15 SP4
SUSE Linux Enterprise Server 15 SP5
Ubuntu 18.04 LTS x64
Ubuntu 20.04 LTS x64
Windows Server 2019
