Product Description
Model: 21SX007ASG
Intel Core Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB
1x 16GB SO-DIMM DDR5-5600
512GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0
Integrated Intel Arc 140T GPU Functions as Intel Graphics
Windows 11 Pro, English (US) / English (UK)
3Y Onsite upgrade from 1Y Courier/Carry-in
Model Configurations
| PERFORMANCE | |
| Processor |
Intel® Core Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB
|
| AI PC Category |
AI PC
|
| NPU |
Integrated Intel® AI Boost, up to 13 TOPS
|
| Graphics |
Integrated Intel® Arc™ 140T GPU Functions as Intel Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
1x 16GB SO-DIMM DDR5-5600
|
| Memory Slots |
Models with U or H series processor: two DDR5 SODIMM slots, dual-channel capable
|
| Max Memory |
Models with Core Ultra processor and Core 7 240H processor: up to 64GB DDR5-5600
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Slot |
Models with U or H series processor: two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot
|
| Max Storage Support |
Models with U or H series processor: up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
|
| Card Reader |
No card reader
|
| Audio Chip |
High Definition (HD) Audio, Senary SN6147 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos®, audio by HARMAN
|
| Microphone |
2x, Array
|
| Camera |
HD 720p with Privacy Shutter
|
| Battery |
64Wh
|
| Power Adapter |
65W USB-C® (3-pin)
|
| DESIGN | |
| Display |
14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz
|
| Touchscreen |
None
|
| Screen-to-Body Ratio |
90%
|
| Pen |
Pen Not Supported
|
| Keyboard |
Backlit, English
|
| Dimensions (WxDxH) |
313 x 220.3 x 10.1/15.25 (front/rear), 20.5 (maximum) mm; 12.32 x 8.67 x 0.40/0.60 (front/rear), 0.81 (maximum) inches
|
| Weight |
Starting at 1.34 kg (2.95 lbs)
|
| Case Color |
Black
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English (US) / English (UK)
|
| Bundled Software |
None
|
| CONNECTIVITY | |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3
|
| WWAN |
Non-WWAN
|
| SIM Card |
None
|
| Ethernet |
100/1000M (RJ-45)
|
| NFC |
None
|
| Standard Ports |
|
| Optional Ports (configured) |
1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), with USB PD 3.1 and DisplayPort™ 1.4
|
| Docking |
Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad E14 Gen 7 (Intel)
|
| SECURITY & PRIVACY | |
| Security Chip |
Discrete TPM 2.0 Enabled
|
| Physical Locks |
Kensington® Nano Security Slot, 2.5 x 6 mm
|
| Smart Card Reader |
None
|
| Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button
|
| Other Security |
|
| MANAGEABILITY | |
| System Management |
Non-vPro®
|
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Onsite upgrade from 1Y Courier/Carry-in
|
| ACCESSORIES | |
| Bundled Accessories |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
| Other Certifications |
TÜV Rheinland® Low Blue Light (Software Solution)
|
