Product Description
5G M2M Router
DWM-550-G
• 5G SA & NSA speeds of up to 3.4 Gbps1 for Internet access and data transfer
• Wi-Fi speeds of up to 1.8 Gbps1 to connect multiple Wi-Fi devices
• 1 x Gigabit Ethernet WAN/LAN port configurable as wired WAN access
• 3 x Gigabit Ethernet LAN port for reliable wired connectivity
• 2 x SIM slots for cellular WAN failover redundancy
• No set up required, simply plug it in and your network is ready to go
• Durable zinc-plated steel case is corrosion-resistant to ensure device longevity
• -30 to 70°C operating temperature to resist harsh environments
• Optional Wall mount bracket allows for optimal device placement
User Benefits
5G SA & NSA
Leverage flexible 4G/5G dual-mode compatibility to adapt seamlessly to diverse carrier networks.
Dual-SIM Failover
Two SIM slots with auto-failover redundancy to ensure uninterrupted cellular WAN connectivity.
Ethernet & 5G Redundancy
Seamless failover between Ethernet WAN and 5G for reliable connectivity.
Industrial-Grade Durability
Corrosion-resistant zinc-plated steel casing and robust design ensure reliable operation in harsh environments.
Secure VPN Protection
Protect sensitive data transmission via secure VPN tunnels to prevent unauthorized network access.
Wi-Fi 6 AX1800
Drive Wi-Fi 6 to cover various portable and IoT device networking services.
Specifications:
Device Interface
• Cellular Module: 5G/4G 3GPP Rel. 16
• Cellular Standards: 5G NR(Sub-6GHz), 4G LTE(DL Cat.19/UL Cat.18)
• SIM Slot: 2*SIM(Nano SIM)
• Ethernet: 1*WAN/LAN GE, 3*LAN GE
• WiFi: Wi-Fi6 AX1800(2.4G/5GHz)
• Power Input: DC 12-36V (TB)
• Antenna Conector: 4*SMA(F)-Cellular, 2*SMA(RP-F)-WiFi
Performance1
• Maximum Cellular Data Throughput:
5G NSA : 3.4 Gbps (DL) / 550 Mbps (UL)
5G SA: 2.4 Gbps (DL) / 900 Mbps (UL)
LTE: 1.6 Gbps (DL) / 200 Mbps (UL)
WAN
• Multi-WAN: Cellular, Ether-WAN, Failover , Load Balance
• Cellular: NAT, Bridge
• Ether-WAN: Dynamic IP, Static IP, PPPoE
• Network Monitor: ICMP Check/DNS Query
Network
• LAN & VLAN: DHCP Server/Relay, Port/Tag based VLAN
• Port Forward: : NAT Loopback, Special AP&ALG, DMZ, Virtual Server & Computer,
VPN Pass-through
• Routing: Static, Dynamic RIPv1/v2, OSPF, BGP
• DDNS: DynDNS, No-IP, Dynamic DO
• QoS: Rule for Service (DSCP, TOS, Well-known Service)
• IGMP, IPv4/v6
Wi-Fi
• Standard: IEEE 802.11 ax/ac/n/g/b/a/h
• Modes: AP Router
• Function: Multi SSID, Auto Channel Selection, Station Isolation
• Security: WPA2-PSK (AES), WPA2, WPA-PSK/WPA2-PSK(AES,TKIP/AES), WPA/WPA2,
WPA3-SAE(AES), WPA2-PSK/WPA3-SAE(AES), WPA3-Enterprise, 802.1x
• Advanced Function: WIDS, Wi-Fi 5G Band Steering
• 2.4GHz Data Rate: 574 Mbps
• 5GHz Data Rate: 1201 Mbps
External Server
Ext. Server: Email, Syslog, RADIUS Server
Service
• Cellular Toolkit: Data usage, SMS, SIM PIN, Network Scan
• Event Handling: Event Management, Notifying Events
VPN
• VPN Tunnel: IPSec, OpenVPN, PPTP,L2TP,GRE, WireGuard
• IPsec Scenario: Site/Host to Site/host; Dynamic VPN
Security
• Firewall: SPI Firewall with Stealth Mode, IPS, Block WAN Ping
• Access Control: Packet Filter, URL Blocking, MAC Control
Administrator
• Configuration: Web UI, CLI, Command Script
• Management: SNMPv1/2/3, D-Link D-ECS2
, RESTful API
• System: FW Upgrade, Backup & Restore Config, Reboot & Reset, System Log, NTP Service
• FTP: FTP, SFTP
• Diagnostic: Diagnostic Tools, Ethernet Port Setup
Status
• Network Status: Connection information, Cellular Signal Quality
• Cellular Mobile: WAN & LAN Interface Network Status, Cellular Modem Status
• Security: VPN Status, Firewall Status
• Statistics&Reports: Connection Session, Login Statistics, Cellular Usage, Cellular Signal
Environment
• OP/Store Temp.:
Operating Temperature -30 to 70 ˚C (-22 °F to 158 °F)
Storage Temperature -40 to 85 ˚C (-40 °F to 185 °F)
• Humidity:
Operating Humidity 10% to 95% non-condensing
Storage Humidity 0 to 95% non-condensing
• Dimensions: 160 x 125 x 35mm
Standard Package:
• 4* Cellular SMA Antennas
• 2* WiFi RP-SMA Antennas
• 1* RJ-45 Cable
• 1* Power Adapter
• 1* Terminal Block (3-pin)
